      Roller Compaction Systems

      IR Range

      A lower cost solution when containment requirements are less stringent.

      RC-IR520-_1_
      BENEFITS

      Pilot to full-scale Roller Compactor Systems



      Robust machines with longevity designed in, delivering a significant return on your investment.

      Our IR range of roller compactors affords different capacity levels, from pilot to full-scale production systems, with directly transferable results from model to model.

      Recognized worldwide as high-performing technology for dry granulation, it offers the flexibility to increase powder density and enhance flow characteristics, improving downstream performance results.

      ICON-pharma-PH-Dry-Granulation-grey-01

      IR 520

      Smaller volume roller compactor

      Ideal for proof-of-concept and smaller volume production work.

      Benefits

      • Results are directly scalable to production equipment.
      • Complete disassembly of all contact parts enables thorough cleaning that is quick and easy to accomplish.
      Model-specific options:

      • Free-standing configurations are available.

      *Results may vary

      50 x 20 cm

      ROLL DIMENSIONS

      26.3 kN/cm

      ROLL FORCE

      1-6 mm

      ROLL GAP

      Up to 150 kg/hr*

      CAPACITY

      Fitz-high-Containment

      IR4LX10D

      Full-scale production roller compactor

      Ideal for full-scale production volumes where containment is less critical.

      Benefits

      • Strong and robust design for durability.
      • Rapid cleaning as parts are easily disassembled / re-assembled. Can also be aggressively cleaned without damage concerns.
      Model-specific options:
      • Free-standing configurations are available.

      * Results may vary

      4 x 20 cm

      ROLL DIMENSIONS

      17.5 kN/cm

      ROLL FORCE

      1-6 mm

      ROLL GAP

      Up to 250-400 kg/hr*

      CAPACITY

      CONTACT THE COMPACTION EXPERTS

      Unsure Which Roller Compaction Machine is Right for You?

      Let us help you achieve a significant return on your investment with the IR range. Complete the form below to request your no-obligation tech consultation.


      Accreditations

      As well as meeting the requirements of cGMP, we want to ensure that the milling machines we develop are well-designed and safe for the operator. To do this we always follow a variety of specific industry directives.

      We offer a complete selection of ATEX and UKEX certified mills that meet the European Union directives and UK Safety Regulations for products used in potentially explosive atmospheres.

      Our equipment is designed to handle the toughest milling applications, which is why professionals around the world choose Fitzpatrick. With models specifically designed to meet Ex Zone 0,20 (1GD)  or 1/21 (2GD) requirements, we provide the most comprehensively safe mills in the industry.

      ATEX compliant milling equipment

      All equipment destined for Europe is CE-marked and UKCA-marked for Great Britain. It comes with an EU or UK Declaration of Conformity or Declaration of Incorporation. European equipment is certified to comply with the Machinery Directive 2006/42/EC, the Low Voltage Directive 2014/35/EU the Electromagnetic Compatibility Directive 2014/30/EU. British equipment is certified to comply with the 2008 Supply of Machinery (Safety) Regulations, 2016 Electromagnetic Compatibility Regulation, and the 2016 Equipment and Protective Systems Intended for Use in Potentially Explosive Atmospheres regulations.

      Our equipment is designed to meet a variety of international safety standards, ensuring that whichever country you are in, we can certify compliance.

      ISO-9001-LOGO-Horizontal
      ATEX_certs
      MODULES

      Our Range of Customer-Driven, Innovative Solutions

      In addition to our market-leading Roll Compaction and Dry Granulation equipment, we also offer solutions that provide afford reliable and repeatable results.
